Nowadays, there are many classifications of motors, and brushless DC frameless torque motor is a relatively special type of motor. Its principle and usage are slightly different from other motors. By mastering its principle and correct usage, it can avoid low-level faults during operation.
1.principle
This motor is a type of motor that is driven by a magnetic field acting on an electric current, and the brake is driven by a direct current voltage. It not only provides high torque and high efficiency output, but also is very convenient to use because there is no mechanical support for magnetic flux.
When current passes through permanent magnets and electric coils to generate a magnetic field, the torque generated is transmitted to the motor shaft. Since the motor is controlled by permanent magnets and electronic devices to generate a magnetic field, a control magnetic field can be generated in the motor to drive its rotation based on the direction and frequency of this magnetic field. This control method provides an extremely accurate, fast, and efficient driving method.
2.Correct usage method
1、Choose the appropriate model
There are various models of brushless DC frameless torque motors, so it is necessary to choose the model that is suitable for your application scenario. Generally speaking, it is necessary to consider factors such as power, speed, voltage, and current when selecting a motor model that meets the usage requirements.
2、install
When installing this motor, attention should be paid to reducing the vibration and noise of the motor. When installing, a suitable fixing method should be selected, and attention should be paid to the fit between the motor and the shaft.
3、connect
Connect this motor to the correct power source and check if the voltage, current, power, etc. are consistent with the design. Generally speaking, the starting current of a motor is relatively high and needs to be appropriately limited.
4、Instructions for Use
When using a brushless DC frameless torque motor, the following points should be noted:
(1)Avoid overloading operation
Overloading operation can have an impact on the motor, leading to damage or reduced lifespan. Therefore, the output power of the motor should be controlled during use.
(2)Add oil and lubricate
The bearings in the motor need regular maintenance, and adding oil and lubrication can extend the service life of the motor.
(3)Prevent motor overheating
Overheating of the motor can lead to a decrease in motor performance, and attention should be paid to heat dissipation during use to ensure that the motor does not overheat.
Brushless DC frameless torque motor has the advantages of high efficiency and light weight. When using, it is necessary to choose the appropriate model, install and connect it correctly, follow the instructions for use, and pay attention to the operating status of the motor to ensure its normal use.
